PRODUCTION EQUIPMENT
Workshop
Advanced smart manufacturing equipment for quality and efficiency
Automatic Pipe Welding Machine
Two automatic pipe welding machines for automated pipe welding
Container Manufacturing
Underframe Assembly Welding Line
Front-end Assembly Welding
Side/Roof Panel Auto Welding
Lower Corrugated Welding Station
Sheet Metal Processing
CNC Bending
YaWei PBH110 Integrated CNC Press Brake
Features advanced control system, imported hydraulic system, and mechanical-hydraulic synchronization mechanism for smooth operation, high precision, and low noise. The all-welded steel frame structure and key structural components (frame, slide, backgauge beam, housing) are machined in a single setup on a European-imported 5-face machining center, ensuring parallelism and perpendicularity of all mounting surfaces.
Laser Cutting
Heqing 6000W Dual-Table Laser Cutter
Common Applications Blanking, contour cutting, secondary cutting, line cutting, irregular hole cutting
Machining Accuracy ± 0.1mm
Precision Cutting & Bending
Precision Cutting
Laser blanking machine cuts panels to preset dimensions (±1mm tolerance), meeting various container specification requirements
Bending & Forming
Cut panels are bent and formed into the panels and frame profiles required for container fabrication
Shot Blasting & Derusting Equipment
High-speed steel shot impacts the steel surface to remove oxide scale and rust, ensuring coating adhesion
Precision Cutting
CNC shearing machine cuts profiles to dimension (±2mm tolerance), meeting various container specification requirements
Pipe Processing
Cantilever Pipe Automatic Welding Machine
Cantilever welding unit with 0-120° manual rotation column. The main unit carrier runs electrically on rails with an effective stroke suitable for welding 6m pipes. Applicable for automatic welding of pipe-to-pipe, pipe-to-elbow, pipe-to-flange, pipe-to-tee, and pipe-to-reducer connections.
CNC Pipe Intersection Line Cutting Machine
Technical Specifications
Pipe Range Ф60-Ф630
Pipe Length 12000mm
Pipe Weight 5000kg
Wall Thickness Plasma straight cut 1-20mm, bevel cut 3-15mm
Cutting Speed 10-2000 mm/min
Intersection Line Cutting Machine
Automated pipe blanking, cutting, and hole drilling
Paint Booth
Full-container painting
Fixtures & Welding Tables
Pipe-to-flange welding and assembly
Surface Treatment — Welding Machine Series
Spot Welder
MIG Welding
TIG Welding Machine
Cabinet Welding
Laser Welding
Pipe gas cutting machine: Beveling and cutting completed in one pass, improving efficiency, ensuring quality, and reducing labor intensity
Portable beveling machine: Creates V, double-V, K, Y and other bevel profiles along weld edges per design requirements before gas or arc welding, ensuring weld quality
MIG/TIG welding equipment includes: arc welders, MIG welders, TIG welders, vertical automatic welders — 16 units in total
